Finishing aspherical optical surfaces

Contraves Inc. our industrial partner needed mathematical guidance to efficiently fabricate the world’s largest single-piece optical element, an 8.3-meter telescope primary mirror. This component now serves as the principal optical component for the Subaru Telescope, sponsored by the National Astronomical Observatory of Japan [NAOJ].

Operator controlled abrasive finishing of aspherical optical surfaces applies a general mathematical theory of abrasive material removal developed by Porsching and Hall in [PHBE1993] to determine non-negative dwell times for polishing machine settings [PH1996], [PHB1998], [B1999].

The Draper machine is configured as depicted in the following schemeatic. We modelled the dynamics of the Draper machine, ultimately leading to software implementing the operator controlled fabracation process.

Modeling the Draper machine for finishing optical surfaces

Modeling the Draper machine for finishing optical surfaces.
